Zyxel Switch Gigabit Ethernet 16-Port R/M UK Plug GS1100-16S - Description
Expand your wired network capacity seamlessly and reliably with the Zyxel GS1100-16S. Engineered for small-to-medium businesses, office workgroups, and demanding home setups, this 16-port unmanaged Gigabit Ethernet switch delivers immediate, wire-speed connectivity without the complexity of software configuration.
High-Performance Unmanaged Connectivity
Featuring 16 auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports and a robust non-blocking 32 Gbps switching capacity, the GS1100-16S ensures seamless data handling for high-bandwidth tasks such as VoIP calls, high-definition video streaming, and rapid local backups. With true plug-and-play design, expanding your network is as simple as connecting your devices and powering on.
Silent and Durable Rackmount Design
Housed in a rugged metal casing, the Zyxel GS1100-16S is built for durability and optimal passive heat dissipation. Its fanless architecture ensures completely silent, 0 dBA acoustic operation, making it an ideal choice for noise-sensitive shared office spaces. The 1U form factor fits seamlessly into standard 19-inch equipment racks using the included brackets, or sits securely on a desktop.
Key Features
- 16 Gigabit Ports: High-density 10/100/1000 Mbps auto-negotiating RJ-45 ports.
- Non-Blocking 32 Gbps Fabric: Delivers full line-rate data transfers across all connected devices simultaneously.
- Fanless, Silent Operation: 0 dBA noise level ensures undisturbed productivity in office environments.
- Energy-Efficient Ethernet (IEEE 802.3az): Intelligently scales power consumption based on traffic and cable length.
- 1U Rack-Mountable Metal Enclosure: Industrial-grade metal chassis designed for desktop use or server rack integration.
- Complete Package: Includes standard UK power plug for instant deployment across Cyprus.
Zyxel Switch Gigabit Ethernet 16-Port R/M UK Plug GS1100-16S - Specifications
General
- Brand
- Zyxel
- Model
- GS1100-16S
- Part Number
- MS-30506
- Switch Type
- Unmanaged Switch
Performance & Switching
- Switching Capacity
- 32 Gbps
- Forwarding Performance
- Wire-speed / Non-blocking architecture
- Jumbo Frame Support
- Supported (up to 9 KB)
- MAC Address Table
- 8K entries
- Packet Buffer
- 525 KB
Ports & Connectivity
- Total Network Ports
- 16
- Port Type
- 10/100/1000 Mbps RJ-45 Gigabit Ethernet
- Auto MDI/MDI-X
- Supported on all ports
- Auto-Negotiation
- Supported
Standards & Protocols
- Ethernet Standards
- IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T
- Flow Control
- IEEE 802.3x Flow Control
- Energy Efficiency
- IEEE 802.3az Energy Efficient Ethernet (EEE)
Physical & Environmental
- Form Factor
- 1U Rackmount / Desktop
- Housing Material
- Metal
- Cooling
- Fanless (Passive Cooling, 0 dBA)
- Power Plug
- UK Standard Plug (Type G)
- Power Supply
- Internal 100-240V AC, 50/60 Hz
