NBMounts P65 Quad Arm Mount 60x40 50-80'' - Description
Elevate your entertainment setup or conference room with the NBMounts P65 Quad Arm Full-Motion TV Wall Mount. Specifically engineered for large, heavy-duty displays ranging from 55 to 85 inches, this premium bracket combines heavy-gauge steel construction with a smart dual cantilever quad-arm design to provide unbeatable strength, safety, and flexible viewing angles.
Unmatched Stability & Full-Motion Flexibility
Whether you need to eliminate glare, angle your screen toward an adjoining room, or tuck it flat against the wall, the NBMounts P65 delivers effortless maneuverability. The articulated quad-arm mechanism smoothly extends up to 500mm away from the wall and folds back to a slim 60mm profile, giving you a clean, space-saving aesthetic without sacrificing adjustability.
Key Features
- Heavy-Duty Capacity: Engineered from high-tensile cold-rolled steel, safely supporting displays up to 68.2 kg.
- Broad Display Compatibility: Perfectly fits most 55-inch to 85-inch flat and curved screens with VESA patterns from 200x200mm up to 600x400mm.
- Smooth Full-Motion Articulation: Offers up to 180° swivel and tool-free tilt adjustment (+8°/-5°) for customized, glare-free viewing.
- Post-Installation Leveling: Integrated +4° to -4° rotational screen level adjustment ensures your TV is perfectly horizontal even after mounting.
- Low Profile & Deep Reach: Extends effortlessly from 60mm to 500mm from the wall for easy cable access and dynamic room positioning.
- Integrated Cable Management: Conceals wires neatly along the arms for a tidy, professional finish.
NBMounts P65 Quad Arm Mount 60x40 50-80'' - Specifications
General
- Brand
- NBMOUNTS
- Model
- P65
- Part Number (SKU)
- MS-22502
- Mount Type
- Full-Motion Quad Arm TV Wall Mount
- Material
- Heavy-Duty High-Tensile Steel
- Color
- Black
Compatibility
- Supported Screen Sizes
- 55" - 85" (also fits most 50"-80" displays)
- Maximum Load Capacity
- 68.2 kg
- VESA Compliance
- 200x200, 300x200, 300x300, 400x200, 400x300, 400x400, 600x400 mm
Motion & Adjustability
- Tilt Angle
- +8° / -5°
- Swivel Angle
- Up to 180° (depends on TV width)
- Screen Level / Rotation Adjustment
- +4° / -4°
- Arm Design
- Dual Extension Quad Cantilever Arm
Physical Dimensions
- Minimum Distance to Wall
- 60 mm
- Maximum Extension from Wall
- 500 mm
- Cable Management
- Integrated Cable Routing System
