Kuwes CAT5E UTP Pure Copper Outdoor 100m Black - Description
Engineered for superior reliability in demanding environments, the Kuwes CAT5E UTP Pure Copper Outdoor Cable (MS-25981) offers professional-grade networking performance. Crafted with 100% solid bare copper 24 AWG conductors, this 100-meter bulk cable guarantees optimal conductivity, reduced signal loss, and exceptional data transmission efficiency, making it the ideal choice for outdoor network extensions, IP surveillance cameras, and perimeter access points.
Robust Weatherproof Protection
Designed to withstand outdoor conditions, the cable is encased in a heavy-duty Low-Density Polyethylene (LDPE) outer jacket with high-density polyethylene (HDPE) conductor insulation. This durable construction provides resilience against moisture, UV exposure, and temperature variations, ensuring uninterrupted connectivity year-round.
Key Features
- 100% Solid Bare Copper: Delivers superior electrical conductivity and signal integrity compared to standard CCA (Copper Clad Aluminium) alternatives.
- Outdoor-Grade LDPE Jacket: Offers heavy-duty protection against weather, abrasion, and environmental wear.
- High-Speed Transmission: Tested for characteristic impedance across 1 to 100 MHz, fully complying with Cat5e standards for fast Ethernet and Gigabit applications.
- Standard Color Coding: Four twisted pairs color-coded for quick, accurate termination with standard RJ45 connectors or patch panels.
- Convenient 100M Roll: Perfect length for medium-to-large residential, commercial, or security installations.
Kuwes CAT5E UTP Pure Copper Outdoor 100m Black - Specifications
General
- Brand
- KUWES
- Model / Part Number
- MS-25981
- Cable Category
- Cat5e
- Cable Type
- UTP (Unshielded Twisted Pair)
- Length
- 100 meters
- Color
- Black
- Installation Environment
- Outdoor
Conductor & Insulation
- Conductor Material
- Solid Bare Copper
- Conductor Size
- 1 x 24 AWG
- Insulation Material
- HDPE (High-Density Polyethylene)
- Insulation Min. Thickness
- 0.153 mm
- Insulation Min. Average Thickness
- 0.178 mm
- Number of Pairs
- 4 Twisted Pairs
- Pair Color Codes
- Pair 1: Blue & White/Blue; Pair 2: Orange & White/Orange; Pair 3: Green & White/Green; Pair 4: Brown & White/Brown
Jacket & Physical Attributes
- Jacket Material
- LDPE (Low-Density Polyethylene)
- Jacket Min. Thickness
- 0.458 mm
- Jacket Min. Average Thickness
- 0.585 mm
- Outer Diameter (O.D.)
- 5.2 mm (±0.3 mm)
Electrical Characteristics
- Characteristic Impedance (Zo)
- 85–115 Ω (1–100 MHz)
- Conductor Resistance
- Max 9.38 Ω / 100m at 20°C
- Resistance Capacitance Unbalance
- 5%
- Pair-to-Ground Capacitance Unbalance
- 330 pF / 100m Max
- Mutual Capacitance
- 5.6 nF / m Max
- Spark Test
- 2.5 KV
