HP DesignJet T630 Printer 24-in - Description
The HP DesignJet T630 24-in is an affordable, professional-grade plotter designed for AEC, GIS, and MCAD professionals who need precision without the high price tag. Known as one of the world's smallest 24-inch plotters, it includes a built-in stand and an automatic sheet feeder, allowing you to print mixed A3 and A1 projects automatically. Its compact design fits perfectly in small offices or home studios, and with HP Click software, you can send multiple files in a single click, saving time from job prep to final print.
Engineered for speed, the T630 delivers sharp, accurate A1-sized prints in as little as 30 seconds (up to 76 A1 prints per hour). It utilizes HP Bright Office Inks to ensure your technical drawings and renderings feature up to 31% more line accuracy and up to 65% more color gamut. With 1 GB of memory and a maximum resolution of 2400 x 1200 optimized dpi, the printer handles complex files efficiently, producing professional results that meet strict industry standards for blueprints and presentations.
The T630 is built with sustainability in mind, featuring a design made with up to 30% recycled plastic. It offers modern connectivity with built-in Wi-Fi, Wi-Fi Direct, and Gigabit Ethernet, making it easy for the whole team to stay connected. Using the HP Smart app, you can manage your plotter and print from virtually anywhere, while HP Wolf Essential Security provides peace of mind by protecting your printer and documents from potential cyber threats.
HP DesignJet T630 Printer 24-in - Specifications
General
- Brand
- HP
- Model
- DesignJet T630 (24-in)
- Model Number
- 5HB09A
- Product Type
- Large-Format Wireless Plotter Printer
- Functions
- Included Accessories
- Printer stand, media bin, automatic sheet feeder, spindle, printhead, introductory ink cartridges
Print Performance
- Print Technology
- HP Thermal Inkjet
- Print Speed
- 26 sec/page on A1 (76 A1 prints per hour)
- Print Resolution
- Up to 2400 x 1200 optimised dpi
- Line Accuracy
- ±0.1%
- Minimum Line Width
- 0.02 mm
- Print Languages
- HP-GL/2, HP-RTL, CALS G4, JPEG, URF
Media Handling
- Model Size
- 24-inch (610 mm)
- Media Types
- Bond and coated paper, technical paper, film, photographic paper, self-adhesive
- Sheet Feeder Size
- 210 x 279 mm to 330 x 482 mm (A4, A3)
- Manual / Roll Feed Size
- 210 x 279 mm to 610 x 1897 mm (A4, A3, A2, A1)
- Standard Sheet Sizes
- A4, A3, A2, A1
- Maximum Roll Diameter
- 100 mm
- Media Thickness
- Up to 0.3 mm (11.8 mil)
Connectivity & Networking
- Ethernet
- Gigabit Ethernet (1000Base-T)
- USB
- Hi-Speed USB 2.0
- Wireless Connectivity
- Wi-Fi 802.11a/b/g/n
- Direct Printing
- Wi-Fi Direct, Apple AirPrint, HP Smart App, HP Click software
Consumables
- Ink Types
- Dye-based (C, M, Y); Pigment-based (K)
- Compatible Cartridges
- HP 712 Black, HP 712 Cyan, HP 712 Magenta, HP 712 Yellow
- Printheads
- 1 (cyan, magenta, yellow, black)
Warranty
- Warranty Period
- One-year limited hardware warranty
